Hay Rakes
Double Rotary Rakes
Photo Gallery
Technical Specifications
WEIGHT 1680 kg
WIDTH 2,5 m
HEIGHT 3,62 m
LENGTH 5,32 m
WORKING WIDTH 5,9 m
POWER 60-80 hp
PTO SPEED 540 rpm
SWATH WIDTH 1,2 m
NUMBER OF ROTORIES 2
NUMBERS OF ROTOR ARM 11x2
NUMBER OF SPRING ARM 4
COLLECTION TYPE Central Collection
TIRE SIZE 340/55-8
(ROTOR) TIRE SIZE 16.5/6.5-8
Featured Properties
SINGLE SIDE WORKING FEATURE
When required, the machine can operate with a single rotor, merging the remaining windrow into an existing one for efficient field collection.
EXCELLENT ADAPTATION TO TERRAINS
The wheels under the rotories provide perfect adaptations and excellent collection in even short ,heavy and wet grass in uneven and slope terrain conditions.
DOUBLE WHEELS
Not to cause a compressive stresson the land,the tyre stepping surfaces enlarged and the left wheels were doubly designed.
EASY TO TRANSPORT
The wings automatically lift to an upright position with the hydraulic system, ensuring smooth transport. Its height below 4 meters meets bridge standards, and the rake’s collecting arms can be easily assembled and disassembled.
OIL BATH GEARBOX
The oil bath gearbox system ensures longlasting and reliable operation, maintains high performance even under heavy working conditions, and requires no maintenance.
